Gemini
The Gemini heavy-duty power wheelchair seamlessly combines comfort with functionality. It’s one of the very few heavy-duty power wheelchairs to offer not only a heavy-duty (450 lbs) capacity but an optional power elevating seat, too! With highly adjustable features, a unique suspension system, and excellent maneuverability, this chair is ready to perform. So, whether you are using it at home or riding through town, the Gemini is a great choice.
Resource Materials
Gemini Specifications
| Product Number | P30111 w/lift, P301 |
| Weight Capacity | 450 lbs, 350 lbs |
| Drivetrain | RWD |
| Seat Type | Captain or Pan |
| Seat Width | P301: 22" P30111: 20” |
| Seat Depth | P301: 22” P30111: 20” |
| Backrest Height | 22" |
| Seat-to-Floor Height | P301: 22”- 24” P30111: 24” - 29” |
| Elevating Seat | P30111 - 5" |
| Overall Length | 41" |
| Overall Width | 24" |
| Overall Height | 45" |
| Turning Radius | 21" |
| Ground Clearance | 4" |
| Total Weight | 242 lbs, 350 lbs |
| Wt of Heaviest Pc | 126 lbs, 146 lbs |
| Max Speed | 5 mph |
| Per Charge Range | up to 20 miles |
| Motor | DC 24V, 240W |
| Controller | P&G VR2 60A |
| Battery Size (2) | 12V/22NF (50AH) |
| Charger | 5A off-board |
| Gradient | 10 ° |
| Front Wheels | 9" foam filled |
| Drive Wheels | 14" foam filled |
| Rear Wheels | 3"anti-tippers |
| Group | Group 2: Heavy Duty |
| HCPCS Code | K0824/K0825 |
| Standard Colors | Red or Blue |
Features
- • 4” ground clearance for easy obstacle clearance
- 14” rubber drive tires for superior traction
- 20” or 22” ergonomic, semi-reclining seats: up to 135°
- Dynamic LiNX controller for easy programming and diagnostics
- Optional 5” power seat lift: reduces weight capacity to 350 lbs.
Options
Swing-away joystick
USB adapter
5”power seat lift
Oxygen tank holder
Cane & crutch holder
Foldable rear basket
Walker holder
XL footplate
Canopy
Elevating legrests
