Color Options


The Gemini heavy-duty power wheelchair seamlessly combines comfort with functionality. It’s one of the very few heavy-duty power wheelchairs to offer not only a heavy-duty (450 lbs) capacity but an optional power elevating seat, too! With highly adjustable features, a unique suspension system, and excellent maneuverability, this chair is ready to perform. So, whether you are using it at home or riding through town, the Gemini is a great choice.

Resource Materials

Gemini Specifications ​

Product NumberP30111 w/lift, P301
Weight Capacity450 lbs, 350 lbs
Seat TypeCaptain or Pan
Seat WidthP301: 22" P30111: 20”
Seat DepthP301: 22” P30111: 20”
Backrest Height22"
Seat-to-Floor HeightP301: 22”- 24” P30111: 24” - 29”
Elevating Seat P30111 - 5"
Overall Length41"
Overall Width24"
Overall Height45"
Turning Radius21"
Ground Clearance4"
Total Weight242 lbs, 350 lbs
Wt of Heaviest Pc126 lbs, 146 lbs
Max Speed5 mph
Per Charge Rangeup to 20 miles
MotorDC 24V, 240W
ControllerP&G VR2 60A
Battery Size (2)12V/22NF (50AH)
Charger5A off-board
Gradient10 °
Front Wheels9" foam filled
Drive Wheels14" foam filled
Rear Wheels3"anti-tippers
GroupGroup 2: Heavy Duty
HCPCS CodeK0824/K0825
Standard ColorsRed or Blue


  • • 4” ground clearance for easy obstacle clearance
  • 14” rubber drive tires for superior traction
  •  20” or 22” ergonomic, semi-reclining seats: up to 135°
  • Dynamic LiNX controller for easy programming and diagnostics
  • Optional 5” power seat lift: reduces weight capacity to 350 lbs.
Gemini profile lift downGemini profile lift up


Swing-away joystick
USB adapter
5”power seat lift
Oxygen tank holder
Cane & crutch holder
Foldable rear basket
Walker holder
XL footplate
Elevating legrests
