Vision Sport with Lift

K0830/K0831

The Vision Sport with Lift combines agile mid-wheel drive performance with powered seat elevation for greater accessibility and independence. Featuring premium ergonomic seating, customizable positioning, robust stability, and a 6.5-inch power lift, it delivers exceptional comfort, maneuverability, and confidence for everyday mobility at home and in the community.

Available colors:

Color swatches for the Merits Health Vision Sport.

Find a Dealer

Download Flier

Product Details

Designed for users who need greater reach without sacrificing maneuverability, the Vision Sport with Lift combines responsive mid-wheel drive performance with a 6.5-inch power seat elevation system.

Premium ergonomic seating, adjustable seat dimensions, and solid drive tires provide lasting comfort and dependable performance, while optional accessories and positioning components allow providers to customize the chair for a wide range of clinical and lifestyle needs.

General Specifications

Weight Capacity:	300 lbs.
Drive Configuration:	MWD
Turning Radius:	21.25"
Ground Clearance:	1.75"
Gradient (Incline):	6°
Range Per Charge:	Up to 18 miles
Overall Length:	36.25"
Overall Width:	23"-27"
Product Weight:	214 lbs.

Seating Details

Seat Type:	Captain or pan seat
Seat Width Options:	16", 18", or 20"
Seat Depth Options:	16-20"
Seat-to-Floor Height:	Captain: 22" + 6.5" lift Pan: 18.75" + 6.5" lift
Backrest Height:	20"
Elevating Seat:	6.5” single post lift

Compatible Accessories

Accessory	Part Number
66" Seat Belt (Standard is 60”):	43700319
80" Seat Belt (Loop Style):	43701
Backpack - Medium 12" x 13" x 3”:	B1117
Backpack - Deluxe 14” x 16” x 4”:	B1121
Cane Holder:	B6212
Cup Holder:	46700060
Cane & Crutch Holder:	34200010
Crutch Holder:	B6213
Cup Holder Mounting Bracket #1:	34103174
Foldable Rear Basket - Medium:	34200019
Foldable Rear Basket - Large:	34200006
Multi-Accessory Receiver Adaptor:	J4M
Oxygen Tank Holder #2:	B6211
Power Wheelchair Cover - Large:	PWCC
Safety Flag:	F1100
Side Bag:	43701032
Unoccupied Transit Tie Down Kit:	39900214
USB Charger:	61230167
Walker Holder #1:	34203010
Walker Holder #2:	B6214

Technical Details

Motor:	DC 24V/160W
Controller:	PG VR2 60A
Battery Size:	35Ah, 12V, U1 (2 required)
Off-Board Charger:	5A
Drive Wheels:	10” foam-filled
Casters:	Front: 6" solid Rear: 6" solid

Coverage & Billing

Medicare Group:	Group 2
Medicare Code:	K0830/K0831

Product Features

Power Seat Lift

A 6.5-inch power elevating seat improves access, social interaction, and everyday reach.

Precision Drive

A compact mid-wheel drive platform with a 20-inch turning radius delivers exceptional maneuverability in tight spaces.

Ergonomic Seating

Premium semi-reclining captain or pan seating reclines up to 135° for personalized comfort and support.

Custom Positioning

Adjustable seat dimensions, optional elevating leg rests, and flexible seating configurations accommodate individual mobility needs.
